TC-100 Automatic Facial Tissue Box Sealing Machine
Overview
TC-100 automatic facial tissue box sealing machine is designed to package facial tissue paper and napkin into boxes and cartons. The steady packing speed is 100 boxes per minute. It is a flexible machine which has wide packing range.
It includes a Nordson adhesive dispenser and controlled by Schneider HMI, motion controller, servo motors and inverters.
Video
Features
- Feed tissue, open box, put tissue into box, mark batch number, dispense hot melt adhesive, seal boxes and output packaged boxes automatically.
- Adopts servo motors to feed tissue paper and put tissue into boxes.
- Adopts high-capacity and faster cartons feeder.
- Feed cartons only when there are products before pusher.
- Adopts Nordson hot melt adhesive dispenser.
- Reliable electrical equipment with famous international brands like Schneider, Omron, Sick, Delta.
- Wide packing range, adjust packing size quickly.
- The machine stops when it is overload.
- Equip safety guide cover.
Technical Data
|
Model |
TC-100 |
|
Packing capacity |
30-100 packs/min |
|
Carton box paper |
300-400 gsm |
|
Carton box size |
100-240 (L) x 100-120 (W) x 20-90 (H) mm |
|
Adhesive Dispenser |
Nordson |
|
Air pressure |
0.5Mpa |
|
Air consumption |
120-160 L/min |
|
Power |
380V 50/60Hz 3phase |
|
Power consumption |
6.2 kW |
|
Machine dimension |
3250 (L) x 1650 (W) x 1800 (H) mm |
|
Machine weight |
2200 kg |
